Poly V

Thanks to its specific design, the Poly V belt can operate in both flexion and reverse flexion, providing greater design flexibility and excellent versatility. It can be used to drive multiple accessories with a single belt in serpentine configurations, while also allowing power transmission from the back of the belt.

Our range also includes various rubber compounds and special coatings, including oil-resistant and antistatic solutions, to meet the requirements of the most demanding applications. The double-sided Poly V belt further extends our range by enabling power transmission on both sides of the belt.

The Ribs are made from a high-performance elastomer compound, providing excellent resistance to abrasion. Their geometry is optimized to maximize the contact surface, ensuring efficient power transmission regardless of the belt width.

The Cord is made of polyester or aramid and forms the textile reinforcement of the belt, directly contributing to its mechanical strength. Our team is available to advise you on the specific dynamic characteristics and performance of these two cord materials.

The Back protects the cord and contributes to the radial stability of the belt’s one-piece structure.

• Molding process: an optimized manufacturing process that minimizes waste while ensuring consistent and controlled belt thickness.
• Excellent flexibility: high flexing and reverse-flexing capabilities.
• Wide temperature range: elastomer compounds suitable for demanding operating environments.
• High operating speed: linear speeds of up to 80 m/s, meeting the requirements of demanding power transmission applications.
• Shock absorption: the belt effectively absorbs load variations, shocks and temporary blockages, helping to protect the transmission system.
