Engine mounting systems
Anti-vibration mount for specific heavy duty engines.
This engine mount is made of one conical elastomeric element enclosed in a cast iron assembly. A built-in adjustable stop limits the vertical and lateral displacement during shock. This mount is available in four different alternatives depending on the type of upper fixing needed.
It can be supplied with or without levelling system and with a threaded hole or a threaded stud.
Improved vibration and sound comfort;
Engine Support Operating Temperature from -10°C to +70°C;
Two versions available;
Silentbloc engine ideal for heavy-duty engines.
key features
Characteristics
This mount has been designed to suspend fixed or mobile generators which require a high level of vibration isolation and shock protection. The load per mount varies from 600 kg to 2300 kg. This load range is covered by 5 different variants (12 to 16) clearly identified by a coloured marking (see table). This mount is available in four different alternatives depending on the type of upper fixing needed:
Resources & documentation
Applications
Machine cabins
Embedded equipment
Motors
